- SPU: AL-VJKV-7bxxg37c[2]
- Specification Model: TCRT5000 Line-Following Module
產品用途：
1、電度表脈衝數據採樣
2、傳真機碎紙機紙張檢測
3、障礙檢測
4、黑白線檢測
產品介紹:
1、採用TCRT5000紅外反射傳感器
2、檢測反射距離：1mm~25mm適用
3、工作電壓：5V
4、輸出形式：數字信號（0和1）
5、設有固定螺栓孔，方便安裝
6、小板PCB尺寸：3.5cm x 1cm
7、單重：4.5g
功能介紹：
TCRT5000傳感器的紅外發射二極管不斷發射紅外線，當發射出的紅外線沒有被反射回來或被反射回來但強度不夠大時，紅外接收管一直處於關斷狀態，此時模塊的輸出端為低電平，指示二極管一直處於熄滅狀態；被檢測物體出現在檢測範圍內時，紅外線被反射回來且強度足夠大，紅外接收管飽和，此時模塊的輸出端為高電平，指示二極管被點亮。
接線方式：
1、VCC:接電源正極（5V）
2、GND:接電源負極
3、OUT:高/低電平開關信號（數字信號0和1）
發貨清單：
1、TCRT5000尋跡模塊1個(已測試好，靜電袋包裝)
