- SPU: AL-E9PH-8p9a3orh[337]
- Interface Type: USB Interface
- Resolution: 600*600
- Type: Handheld Scanner
- Scanning Speed: 500 times/second
- Warranty: One Year
- Weight: 600g
- After-Sales Service: Online Technical Support/One-Year Warranty
- 3C Certificate Number: 2022010907447750
- Model: 1D Laser Paper Code
- Model: 1D Red Light Paper Code + Screen Code
- Model: 2D Model (1D + QR Code Paper Code + Screen Code)
- Is it a Gift: No
【裝箱資料】
1PCS, 重量：0.7KG，包裝尺寸：22.5*13*14.2
1箱：20PCS, 重量：12KG, 包裝尺寸：68*47*31、
【產品特點】
1.支持掃描一維碼和二維碼，掃描靈敏度高，掃描速度快。
2.支持多國語言，出口方便。
3.工業級性能，支持2米防摔。
4.無線+藍牙傳輸模式。
5.支持商超，物流快遞，醫院，餐飲，等需要掃描條形碼的場景下使用。
6.電池容量：1200毫安。
| 無線傳輸距離 （空曠環境） |
100 米 | |
| 光源 | 620nm可見紅光二極管 | |
| 圖像傳感器 | CMOS | |
| 分辨率 | 30萬像素 | |
| 識讀精度 | ≥ 3mil | |
| 最低對比度 | ≥ 30% | |
| 識讀碼制 | 一維 CODE128, EAN-8, EAN-13, UPC-E, UPC-A, Interleaved 2 of 5, ITF14, MATRIX 25, Code39, Codabar, Code93, UCC/EAN-128, Code11, ISBN, INDUSTRIAL25, STANDARD25, Plessey, MSI_Plessey 二維、 PDF417, QR, Aztec, DataMatrix, Maxicode |
|
| 條碼靈敏度** | 傾斜 | ±55° |
| 旋轉 | ±25° | |
| 偏轉 | ±75° | |
| 機械和電氣性能 | ||
| 外觀尺寸(長 x 寬 x 高) | 107mm×88mm×167 mm | |
| 重量（不含配線） | 210g | |
| 提示方式 | 蜂鳴器和LED指示 | |
| 電池容量 | 1000mah | |
| 最大功耗 | 1176mw | |
| 工作電壓 | 4.2V | |
| 電流** | 最大電流 | 280mA |
| 工作電流 | 84mA～280mA | |
| 待機電流 | 84mA | |
| 休眠電流(無線產品) | ﹤10uA | |
| 充電電流 | 450mA | |
| 電池充電時間 | 充滿電最長需要3.5小時 | |
| 一次充滿電可讀條碼 | 大於10萬次 | |
| 環境參數 | ||
| 儲存溫度 | -40°C ~ 60°C | |
| 工作溫度 | 0°C ~ 50°C | |
| 相對濕度 | 0 ~ 95% (無凝結) | |
| 跌落高度（自由落下） | 1.5米 | |
| IP防護等級 | IP52 | |
| **測試條件如下：Code 39, 3 Bytes ; 最小條空寬度 = 10mil; 寬窄比 = 2.5:1 ; 條碼高度 = 40mm；測試距離 = 180mm;環境溫度=25℃ ; 環境照度= 200 LUX | ||
After sales information
Within 15 days from the date of receipt, customers can be provided with an unconditional return service. The application for return of goods requires the consent of the merchant in the store.
Procurement and delivery
Delivery time: For products in stock, they will be shipped within 3 working days (excluding holidays) after you place your order and make payment. You will receive our notification after shipment.
payment
Credit card payment (quick payment) is a new payment method jointly launched by third-party payment platforms and major banks. It is one of the safest and easiest payment methods. Users do not need to activate online banking in advance, they can complete quick payments by entering information such as card face and mobile phone dynamic password. Quick payment allows various bank card users to conveniently make online payments without the need for special online banking activation.
