- SPU: AL-E9PH-8p9a3orh[337]
- 接口類型:USB接口
- 分辨率:600*600
- 類型:手持式掃描槍
- 掃描速率:500次/秒
- 質保:一年
- 重量:600g
- 售後服務:線上技術支持/質保一年
- 3C證書編號:2022010907447750
- 型號:一維激光款紙質碼
- 型號:一維紅光款紙質碼+屏幕碼
- 型號:二維款一維+二維碼紙質碼+屏幕碼
- 是否屬於禮品:否
【裝箱資料】
1PCS, 重量:0.7KG,包裝尺寸:22.5*13*14.2
1箱:20PCS, 重量:12KG, 包裝尺寸:68*47*31、
【產品特點】
1.支持掃描一維碼和二維碼,掃描靈敏度高,掃描速度快。
2.支持多國語言,出口方便。
3.工業級性能,支持2米防摔。
4.無線+藍牙傳輸模式。
5.支持商超,物流快遞,醫院,餐飲,等需要掃描條形碼的場景下使用。
6.電池容量:1200毫安。
無線傳輸距離 (空曠環境) |
100 米 | |
光源 | 620nm可見紅光二極管 | |
圖像傳感器 | CMOS | |
分辨率 | 30萬像素 | |
識讀精度 | ≥ 3mil | |
最低對比度 | ≥ 30% | |
識讀碼制 | 一維 CODE128, EAN-8, EAN-13, UPC-E, UPC-A, Interleaved 2 of 5, ITF14, MATRIX 25, Code39, Codabar, Code93, UCC/EAN-128, Code11, ISBN, INDUSTRIAL25, STANDARD25, Plessey, MSI_Plessey 二維、 PDF417, QR, Aztec, DataMatrix, Maxicode |
|
條碼靈敏度** | 傾斜 | ±55° |
旋轉 | ±25° | |
偏轉 | ±75° | |
機械和電氣性能 | ||
外觀尺寸(長 x 寬 x 高) | 107mm×88mm×167 mm | |
重量(不含配線) | 210g | |
提示方式 | 蜂鳴器和LED指示 | |
電池容量 | 1000mah | |
最大功耗 | 1176mw | |
工作電壓 | 4.2V | |
電流** | 最大電流 | 280mA |
工作電流 | 84mA~280mA | |
待機電流 | 84mA | |
休眠電流(無線產品) | ﹤10uA | |
充電電流 | 450mA | |
電池充電時間 | 充滿電最長需要3.5小時 | |
一次充滿電可讀條碼 | 大於10萬次 | |
環境參數 | ||
儲存溫度 | -40°C ~ 60°C | |
工作溫度 | 0°C ~ 50°C | |
相對濕度 | 0 ~ 95% (無凝結) | |
跌落高度(自由落下) | 1.5米 | |
IP防護等級 | IP52 | |
**測試條件如下:Code 39, 3 Bytes ; 最小條空寬度 = 10mil; 寬窄比 = 2.5:1 ; 條碼高度 = 40mm;測試距離 = 180mm;環境溫度=25℃ ; 環境照度= 200 LUX |
