$6.90 | 55-degree aluminum using a roughing end mill with a straight shank, wave edge carbide three-edged aluminum roughing end mill manufacturer tungsten steel knife

55-degree aluminum using a roughing end mill with a straight shank, wave edge carbide three-edged aluminum roughing end mill manufacturer tungsten steel knife

$6.90

sales volume: 1

classification: Hardware tools , Cutting tool , Other milling cutters

colour

D4*50 D6*50 D8*60 D8*75 D10*75 D10*100 D12*75 D12*100 D14*100 D14*150 D16*100 D16*150 D20*100 D20*150

size

Free Size

number

Buy now

SPU: AL-2YEQ-9f0inw4p[330]
Model:D4*50
Model:D6*50
Model:D8*60
Model:D8*75
Model:D10*75
Model:D10*100
Model:D12*75
Model:D12*100
Model:D14*100
Model:D14*150
Model:D16*100
Model:D16*150
Model:D20*100
Model:D20*150
Ball diameter (mm):0
Chamfer angle:45
Minimum cutting diameter at center (mm):1mm
Maximum cutting depth:80
Number of effective cutting edges:3
Functional length (mm):3 times the diameter
Helix angle:35
Shank type:-
Standard: CNC grinding machine
Effective length (mm):3 times the diameter
Series:55-degree aluminum roughing end mill
Cutting edge form:Side milling and插铣
Material:Tungsten carbide
Type:Flat milling cutter
Number of grooves:3
Edge length:3 times the diameter
Total length:50-200mm
Coating:Non-coated
Machine tool suitable for: Milling machine
Processing range:Aluminum and copper parts
Specification (diameter*total length):4*12*50*3F
Maximum cutting diameter (mm):20
Product type: Milling cutter
