$5.90 | Step-down voltage conversion module 4.5-18V to 3/3.3V/3.7/4.2V/5V/6V motor LED power supply

Step-down voltage conversion module 4.5-18V to 3/3.3V/3.7/4.2V/5V/6V motor LED power supply

$5.90

sales volume: 3

classification: Hardware tools , electric control , Switching Mode Power Supply

colour

5-18V to 3V

5-18V to 3V3

5-18V to 3V7

5-18V to 4V2

6-18V to 5V

7-18V to 6V

size

One size fits all

number

Buy now

SPU: AL-Q0QG-7seuwihx[A0]
Model: 5-18V to 3V
Model: 5-18V to 3V3
Model: 5-18V to 3V7
Model: 5-18V to 4V2
Model: 6-18V to 5V
Model: 7-18V to 6V
Power supply type: switching power supply

Shipping list: 1 buck conversion module

( This product has 3V/ 3.3V/ 3.7V/ 4.2V/ 5V/ 6V/ 6 output voltages are available, please choose the voltage you need)

Product Description:

3V: Enter DC 4.5~ 18V, output DC 3V
3.3V: Input DC 4.5~ 18V, output DC 3.3V
3.7V: Enter DC 4.5~ 18V, output DC 3.7V

4.2V: Input DC 4.5~ 18V, output DC 4.2V
5V: Enter DC 6~ 18V, output DC 5V
6V: Enter DC 7~ 18V, output DC 6V

The maximum output current is 2A, and the maximum output current in a short time is 3A.
DC- DC step-down conversion module, operating frequency 500KHZ, conversion efficiency 77-93%
Quiescent operating current: 216- 18mA
It has overheating shutdown, input undervoltage protection, overcurrent protection, and output short circuit protection.
Operating temperature: –40°C to +85°C
Size: 27 x 18 x 5mm
weight: about 4 grams

Notice:

This is a voltage step-down conversion module. The following conditions must be followed when using it.:
1 The input voltage cannot be greater than the nominal voltage, otherwise the module will be burned out.
2 The input power must be greater than the output power, otherwise the output voltage will be less than the nominal voltage.
3 The output load cannot be greater than the nominal load, otherwise the output voltage will be less than the nominal voltage.
4 This is a high-power module. Be sure to use thick enough wires and make good contact.

Wiring diagram:

undefined

How to drive a motor( Motor)?

1 via motor driver

2 positive and negative series diodes

Changing the value of resistor R1 can change the output voltage
