- SPU: AL-6FBF-87isvjoo[8]
- Model: 3 strings
- Model: 4 strings
- Model: 5 strings
- Model: 6 strings
- Model: 7 strings
- Model: 8 strings
- Accessory name: Battery balancing board
- certified product:-
3/4/5/6/7/ 8 string 18650 lithium battery polymer battery balancing board 11.1~ 33.6V 8S charging
3 String battery balancing board parameters: prefix= o n= " urn: schemas- microsoft- com: office: office"
Features:
4.2V The equilibrium voltage and equilibrium current are 66mA;
Solder joint instructions:
B4 No need to answer
B3 Connect the positive terminal of the battery pack
B2 Connect the battery2 with battery3 contacts in
B1 Connect the battery1 with battery2 contacts in
B - Connect the negative terminal of the battery pack;
Product Size:26*20.5* 2.4mm
4 String battery balancing board parameters:
Features:
4.2V balanced voltage, balanced current is 66mA;
Solder joint instructions:
B4 is connected to the positive terminal of the battery pack
B3 Connect the contacts between battery 1 and battery 2
B2 connects the contacts in battery 2 and battery 3
B1 is connected to the contacts in battery 3 and battery 4
B－ Connect to the negative pole of the battery pack;
Product Size:26*20.5* 2.4mm
5 String battery balancing board parameters:
Features:
4.2V balancing function, the action current is 68mA;
Welding point instructions:
· B5+ Connect the positive terminal of the battery pack;
· B4+ Connect the battery4 with battery5 contacts in;
· B3+ Connect the battery3 with battery4 contacts in;
· B2+ Connect the battery2 with battery3 contacts in;
· B1+ Connect the battery1 with battery2 contacts in;
·B - Connect the negative terminal of the battery pack;
Product Size:37.3*25.8* 2.4mm
6 String battery balancing board parameters:
Features:
4.2V The equilibrium voltage and equilibrium current are 66mA;
Solder joint instructions:
B - Connect the negative terminal of the battery pack
B1 Connect the battery1 with battery2 contacts in
B2 Connect the battery2 with battery3 contacts in
B3 Connect the battery3 with battery4 contacts in
B4 Connect the battery4 with battery5 contacts in
B5 Connect the battery5 with battery6 contacts in
B6 Connect the positive terminal of the battery pack
Product Size:37.3*25.8* 2.4mm
7 String battery balancing board parameters:
Features:
4.2V The equilibrium voltage and equilibrium current are 66mA;
Solder joint instructions:
B - Connect the negative terminal of the battery pack
B1 Connect the battery1 with battery2 contacts in
B2 Connect the battery2 with battery3 contacts in
B3 Connect the battery3 with battery4 contacts in
B4 Connect the battery4 with battery5 contacts in
B5 Connect the battery5 with battery6 contacts in
B6 Connect the battery6 with battery7 contacts in
B7 Connect the positive terminal of the battery pack
Product Size:37.3*25.8* 2.4mm
8 String battery balancing board parameters:
Features:
4.2V The equilibrium voltage and equilibrium current are 66mA;
Solder joint instructions:
B - Connect the negative terminal of the battery pack
B1 Connect the battery1 with battery2 contacts in
B2 Connect the battery2 with battery3 contacts in
B3 Connect the battery3 with battery4 contacts in
B4 Connect the battery4 with battery5 contacts in
B5 Connect the battery5 with battery6 contacts in
B6 Connect the battery6 with battery7 contacts in
B7 Connect the battery7 with battery8 contacts in
B8 Connect the positive terminal of the battery pack
Product Size:37.3*25.8* 2.4mm
